System 07 / 12
2.0 mm twist-off · 3.0 mm cannulated
Screw Sets
Titanium fixation across two systems.
Configuration 01
- Division
- Med-Tech
- Systems
- 2.0 mm twist-off · 3.0 mm cannulated
- Material
- Titanium
- 2.0 mm lengths
- 11 – 20 mm
01 — Overview
The system.
Two titanium screw systems supplied as complete sets. The 2.0 mm twist-off screw is self-drilling and self-tapping, available in eight lengths. The 3.0 mm cannulated system covers a wider length range for larger fixation.
02 — Design features
Engineered in.
- Titanium construction
- Self-drilling, self-tapping 2.0 mm twist-off design
- 3.0 mm cannulated system with guide-pin range
- Length increments of 1–2 mm
03 — Specification
On the label.
Systems
2.0 mm twist-off · 3.0 mm cannulated
Material
Titanium
2.0 mm lengths
11 – 20 mm
3.0 mm lengths
14 – 48 mm
04 — Catalogue
Reference numbers.
2.0 mm twist-off screw
8 references
| Length | Catalogue |
|---|---|
| 11 mm | LA-007-11 |
| 12 mm | LA-007-12 |
| 13 mm | LA-007-13 |
| 14 mm | LA-007-14 |
| 15 mm | LA-007-15 |
| 16 mm | LA-007-16 |
| 18 mm | LA-007-18 |
| 20 mm | LA-007-20 |
3.0 mm cannulated system
18 references
| Length | Catalogue |
|---|---|
| 14 mm | LA-008-14 |
| 16 mm | LA-008-16 |
| 18 mm | LA-008-18 |
| 20 mm | LA-008-20 |
| 22 mm | LA-008-22 |
| 24 mm | LA-008-24 |
| 26 mm | LA-008-26 |
| 28 mm | LA-008-28 |
| 30 mm | LA-008-30 |
| 32 mm | LA-008-32 |
| 34 mm | LA-008-34 |
| 36 mm | LA-008-36 |
| 38 mm | LA-008-38 |
| 40 mm | LA-008-40 |
| 42 mm | LA-008-42 |
| 44 mm | LA-008-44 |
| 46 mm | LA-008-46 |
| 48 mm | LA-008-48 |
Screw Sets · Supplied on enquiry · AU / NZ
Enquire about Screw Sets.
Supplied to healthcare professionals across Australia and New Zealand. Our team can provide specifications, instrumentation detail and availability.
Specifications and catalogue references are provided for product identification and are subject to confirmation. Refer to the Instructions for Use supplied with each device for indications, contraindications and warnings.
